Maximum theoretical conveying capacity: 30 cubic meters

Maximum outlet pressure: 10Map

Allowable concrete slump: 200-230

Hopper capacity: 0.3

Loading height: 500

Material cylinder specification: 140 * 800

Main oil cylinder: 80-650

Diesel engine model: 4105

Engine power: 65KW

Maximum pressure of hydraulic system: 20Map

Fuel tank capacity: 120L

Specification of radiator: 1317L/min

Electrical control mode: programmabl
